High configuration batch eps pre-expander machine with twice foaming function

Specification

Feature

1. Inside and outside of barrel are both made of stainless steel; And middle layer is heat preserving material. The machine has the advantages of high thermal efficiency, Penetrating strong, so it can make the foamed beads all with same size.
2. The machine is controlled by PLC full computer touch screen displayer which can realize a full automatic cycle operation of material feeding, steam feeding, temperature controlling, foaming and discharging. And the electronic weighting filling realize quantitative material is exactly and rapidly fed after compressed.
3. The foaming process in the machine is realized in a fully closed stainless steel barrel under constant pressure with high thermal efficiency, economized steam, shortened curing process and high foaming magnification.
4. The machine is composed by famous-brand and high-quality pneumatic elements which can supply a reliable quality and convenient operation to ensure a precise temperature control and uniformity of beading and density.
5. This machine can be matched with sulfurization dryer to realize a continuous operation of drying, screening, breaking and conveying of material for foaming.

6. The machine’s computer can record frequently used Raw material with brand, size special and foaming technology etc information that will be more convenience.

Parts assembled

Machine support,barrel,fan,drying box(optional),pressure reducing valve,proportion control valve,angle seat valve,spiral feeding device,weighing device,twice foam device,screen touch type contol box,materials volume switch,reducer,pressure sensor,temprature control etc

Configuration Brand

 Delixi,Yoshitake,Delta
